Basic Info
Model No.: YP2000F-L
Applicable Industry: Food, Gift, Handicraft, Alcohol and Tobacco
Packaging Type: Cans
Type: Automatic Wrapping Machine
Driven Type: Electric
Application: Fruit Drinks, Pure Water, Yogurt
Automatic Grade: Automatic
Inclusion Degree: Fully Wrapped Winding Machine
Structure: No Pallet Wrapping Machine
Film Frame Structure: Pre Tension
Series: Y Series Cylinder Type Axial Winding Machine
Additional Info
Packaging: Export package
Productivity: 50 sets per month
Brand: Dyehome
Transportation: Ocean,Land
Place of Origin: China
Supply Ability: 50 sets per month
Certificate: CE
HS Code: 84224000
Port: Qingdao Port,Shanghai Port,Ningbo Port
Product Description
Automatic reel stretch Wrapping Machine
YP2000F Paper roll Stretch Film Wrapping Machine
1.Machine introduction:
Y Series Reel Wrapper is a machine designed for packing rolls of paper, film, dipped tire cord
fabric and similar materials manufactured in reels. It is ideal for reel axial wrapping-across the cylindric diameter then along the longitudinal axis . This packing method can form a
cocoon type packing. It is completely Moisture Water & Dust proof packing and protects the products.
2,Technical Parameter.
|
HYP2000F-L paper roll wrapping machine |
|
|
Size of the product to be wrapped |
|
|
Paper roll diameter |
500-1600 mm (Special can be made) |
|
Paper roll width |
500-1600 mm (Special can be made) |
|
Max weight capacity |
2000kgs |
|
Machine Specification |
|
|
Turntable rotation speed: |
3-12 rpm adjustable |
|
Turntable diameter |
2000mm |
|
Turntable roller center distance |
460mm |
|
Turntable roller diameter |
150mm |
|
Turntable height |
460mm Standard |
|
Carriage Up/down speed |
Adjustable |
|
Power supply voltage |
230 Volt 1 Ph – 50 Hz |
|
Power |
2.3 Kw |
|
Machine size |
3000mm x 2000mm x 2200mm (LXWXH) |
|
Machine weight |
1080kg |
|
Packing efficiency |
20-40 loads/hour |
|
Film Roll detail |
|
|
Max. external diameter (D): |
230 mm |
|
Film roll height (h): |
500 mm |
|
Film thickness: |
17-35 µm |
|
Internal diameter (d): |
76 mm |
|
Option |
|
|
Paper roll auto-ejection system (Machine Model: YP2000F-AU) |
|
|
Top platen system (Machine Model: YP2000F-CS) |
|
|
Turntable Slew bearing drive (Machine Model: YP2000F-BT) |
|
